SFP28 ER BIDI

SFP28 ER BIDI

The SFP28 ER BIDI optical module features a 1270nm DFB laser and a PIN receiver, with an LC interface. The commercial version consumes ≤1.2W, while the industrial version consumes ≤1.5W, both powered by 3.3V. The commercial version operates from 0 to 70°C, and the industrial version from -40 to 85°C, supporting Digital Diagnostics Monitor (DDM). It is suitable for 25G Ethernet applications and can transmit data over 40km on G.652 single-mode fiber.

Product Features

•Support data rate up to 25.78125Gb/s

•Hot-Pluggable SFP Footprint and Single LC Connector

•Up to 40km reach for G.652 SMF

•DFB TX and Integrated APD RX

•RoHS 6 compliance

•Maximum power dissipation：C-temp≤1.2 W，I-temp≤1.5W

•Operating temperature range：Commercial(0°C ~+70°C),Industrial(-40°C ~+85°C)

•Compliant to IEEE 802.3cc, SFF-8472 and SFF-8419

•Complies with EU Directive 2015/863/EU

Use Cases

25G Ethernet

CPRI option 10

Product Specifications

Product Name：

SFP28 ER BIDI

Center Wavelength(nm)

1270

1310

Reach

40Km

Tx Power(dBm)

0~ 6dBm

Sensitivity

≤-19dBm@5E-5

Temp(℃)

0 ~ 70℃

Consumption

＜1.2W
