QSFP28 DR1

QSFP28 DR1

The QSFP28 DR1 optical module employs 1310nm EML lasers and PIN receivers, featuring LC connectors. It consumes less than 4W of power with 3.3V供电, operates within a temperature range of 0~70℃, and supports Digital Diagnostics Monitor (DDM) functionality. Compliant with standards such as IEEE 802.3cu, it is designed for data centers and 100G Ethernet applications, supporting transmission distances of up to 500m over 9/125μm single-mode fiber.

Product Features

•Compliant with IEEE 802.3cu

•Compliant with SFF-8679 MSA hardware specification

•Compliant with SFF-8636

•Compliant with SFF-8661

•1310nm EML laser

•PIN receiver

•Up to 500m on 9/125um SMF

•100ohm differential impedance system

•Operating temperature options(Commercial) 0℃ to +70 ℃

•Trouble-free installation and network bring-up

•RoHS Compliant

Use Cases

Data Center

100 Gigabit Ethernet

Product Specifications

Product Name：

QSFP28 DR1

Center Wavelength(nm)

1311

Reach

500m

Tx Power(dBm)

﹣0.8~ 4.5dBm

Sensitivity

≤-3.9dBm@5E-5

Temp(℃)

0 ~ 70℃

Consumption

＜3.5W

Product Comparison

Product One
Product Two
Product Three
