QSFP28 ZR4

QSFP28 ZR4

The QSFP28 ZR4 optical module features a 4x25Gb/s electrical interface, equipped with cooled LAN WDM EML transmitters and PIN+SOA receivers, and uses an LC connector. The commercial version consumes less than 5.5W and operates at temperatures between 0°C and 70°C, while the industrial version consumes less than 6.5W and operates between -40°C and 85°C. It supports DDM functionality and is suitable for 100GBASE-ZR4 Ethernet, capable of transmitting over 80km on G.652 single-mode fiber.

Product Features

•Up to 80km reach for G.652 SMF

•Cooled 4x25Gb/s LAN WDM EML TOSA with optical MUX

•High Sensitivity PIN and SOA

•4x25G Electrical Interface

•Single +3.3V power supply

•DDM function implemented

• 2 Wire Serial Interface for module management

•Maximum power dissipation(Commercial：< 5.5W,Industrial：<6.5W)

•Operating temperature range(Commercial：0℃ ~ 70℃,Industrial:-40℃~85℃)

•Compliant with RoHS6

Use Cases

100GBASE-ZR4 Ethernet

100G Datacom& Telecom connections

100G 4WDM-40

Product Specifications

Product Name：

QSFP28 ZR4

Center Wavelength(nm)

1294.53 – 1296.59

1299.02 – 1301.09

1303.54 – 1305.63

1308.09 – 1310.19

Reach

80Km

Tx Power(dBm)

1 ~ 6.5dBm

Sensitivity

≤-27dBm

Temp(℃)

0 ~ 70℃

Consumption

＜5.5W
