QSFP-DD DAC

QSFP-DD DAC

The QSFP-DD DAC optical module supports a total data rate of 400Gbps (PAM4) using 28/30AWG cables and a 76-pin edge connector. It is powered by 3.3V and operates within a temperature range of 0~70°C, complying with IEEE 802.3bj/cd and RoHS standards. Suitable for data center networks, it supports direct and branch configurations and offers customizable EEPROM mapping.

Product Features

•Compatible with IEEE 802.3bj and IEEE 802.3cd

•Supports aggregate data rates of 400Gbps(PAM4)

•Optimized construction to minimize insertion loss and crosstalk

•Pull-to-release slide latch design

•Straight and break out assembly configurations available

•Customized cable braid termination limits EMI radiation

•Customizable EEPROM mapping for cable signature

•28AWG and 30AWG cable

•3.3V Power supply

•Temperature Range: 0~ 70℃

•RoHS Compliant

Use Cases

Data Center networks

High performance computing

Telecommunication and wireless infrastructure

Medical diagnostics and networking

Test and measurement equipment

Switches, servers and routers

Storage area networks

Product Specifications

Product Name：

QSFP-DD DAC

Center Wavelength(nm)

Reach

Tx Power(dBm)

Sensitivity

Temp(℃)

0 ~ 70℃

Consumption

Product Comparison

Product One
Product Two
Product Three
